Powered by two Rolls-Royce BR725
turbofan engines
PlaneView Il avionics suite with Synthetic Vision System and HUD
Range of 7,500 NM and requires no structural modifications
1 US corporate owner since new
KaBand WiFi
Fresh 12/24/48 Month Inspections
Full Block III Upgrade
Rolls Royce Corporate Care
Honeywell MSP Gold
Total Hours: 2862.3 Hours
Total Landings: 1271 Landings
Engines Enrolled on Rolls Royce Corporate Care
Engine Model: Rolls-Royce Derby PLC BR725A1-12
Engines: Engine 1
Serial Number: 25797
Time Since New: 2862.3 Hours
Engine Cycles: 1271 Cycles
Engines: Engine 2
Serial Number: 25796
Time Since New: 2862.3 Hours
Engine Cycles: 1271 Cycles
Gulfstream PlaneView II / Honeywell Primus Epic Avionic
Triple Modular Avionics Units
Four (4) Large 14” Adaptive LCD Displays
Rockwell Collins Head Up Display (HUD II)
Enhanced Vision System (EVS II)
Synthetic Vision – Primary Flight Display (SV-PFD)
Emergency Vision Assurance System (EVAS)
Triple VHF Navigation Systems
Triple VHF Communication Systems
Dual Standby Multifunctional Controllers
Triple NextGen Flight Management Systems (FMS)
Triple Inertial Reference System (IRS) LASEREF VI
Four (4) Multifunction Air Data Probes
Automatic Emergency Descent Mode (EDM)
PlaneView II XM WX Weather
RDR-4000 3-D Weather Radar
FANS-1A (CPDLC/ADS-C)
Datalink VDL Mode 2
Dual 24-Channel GPS w/WAAS, LPV
ADS-B Out DO-260B
Lateral Precision Vertical (LPV) Approach Capability
Dual (Mode S) Transponders
Traffic Collision Avoidance System (TCAS II)
Enhanced Ground Proximity Warning System w/Windshear
Digital Flight Data Recorder (FDR)
Cockpit Voice Recorder (Data-Link Recording)
ACARS w/Satellite Communication Link & Flight Deck Printer
Triple-Frequency Emergency Locator Transmitter (ELT)
Runway Awareness Advisory System (RAAS)
Predictive Windshear (PWS)
ADDITIONAL EQUIPMENT/ASC COMPLIANCE:
KA Band Wifi
Full Block III ASC Compliance
Planeview Avionics Enhancement ASC 100A
Master Operating System Update ASC 903A
Predictive Weather ASC 120
Situational Awareness ASC 121
HUD II Update ASC 125
Predictive Landing Performance ASC 127
Auto-Pilot Coupled TCAS ASC 128
Flap Self-Aligning Rollers Installed
15 Passenger Executive Configuration
Forward Crew Lav & Rest Compartment
Forward Galley with Galley Annex and Custom Storage
Zone 1: Four (4) Place Club w/Console Tables
Zone 2: Four (4) Place Conference Group Opposite Two (2) Single Seats
Zone 3: Two (2) Place Club Opposite a Three (3) Place Berthable Divan
Three (3) External HD Cameras (ASC078)
Aft Lavatory & Large Aft Baggage Compartment
Matterhorn White w/ Blue, GlossBlack, Soft Grey, Sunfast Red Accents.
